What are your thoughts concerning How to Install a Bathtub Yourself?


Installing A Bathtub
Setting up a bathtub isn't specifically rocket science, but it does require solid plumbing, carpentry, and in some cases, tiling abilities. Changing an old bathtub with a new one is likewise a moderately hard task. If the old bathtub is easily obtainable, the project can move immediately; if you have to open a wall surface to remove the old tub and position the new tub, the job is much harder. In either instance, the job is within a home handyman's skills, although you will certainly require an assistant to move out the old tub and also embeded in the brand-new one. Make sure you have qualified yourself for the task and fit trying it. Instead of working with a service provider to take over a halfway-completed project, it is much better to take into consideration utilizing one before you start. Possibilities are you may require a professional plumber to make tube links.
This write-up will assist you mount a brand-new bathtub in your restroom if you have currently purchased a brand-new bathtub and also don't need to transform the arrangement of your previous water supply pipelines.
Your tools as well as product list should consist of the following:
  • New Bath tub

  • Hammer

  • Pipeline Wrenches

  • Prybar

  • Safety Glasses

  • Level

  • Pliers

  • Flexible Wrench

  • Putty Knife

  • Screwdriver

  • Cold Knife

  • Tape Measure

  • Pipe Caps


  • Removing Old Taps


    If you require to change old taps with new ones as a part of your installment, then the first thing you should do is separate the supply of water. After doing so, turn on the taps to drain pipes any water continuing to be in the system. The process of getting rid of the existing taps can be fairly bothersome as a result of the restricted accessibility that is usually the situation.
    Make use of a basin wrench (crowsfoot spanner) or a tap device to undo the nut that attaches the supply pipes to the faucets. Have a fabric ready for the continuing to be water that will certainly come from the pipes. When the supply pipelines have been gotten rid of, make use of the very same tool to loosen the nut that holds the taps onto the bath/basin. You will certainly need to stop the solitary faucets from transforming throughout this procedure. As soon as the faucets have actually been removed, the holes in the bath/basin will need to be cleansed of any type of old sealing substance.
    Before carrying on to fit the new faucets, contrast the pipe links on the old taps to the brand-new faucets. If the old faucets are longer than the brand-new taps, after that a shank adapter is needed for the new faucets to fit.

    Suitable New Touches


    If the tails of the brand-new taps are plastic, then you will require a plastic adapter to stop damages to the string. One end of the adapter fits on the plastic tail of the faucet and also the other end supplies a link to the current supply pipes.
    If you require to fit a monobloc, then you will certainly need lowering couplers, which attaches the 10mm pipe of the monobloc to the common 15mm supply pipe.
    Next off, place the faucet in the placing opening in the bath/basin making certain that the washing machines are in area in between the faucet and the sink. Secure the faucet in position with the producer given backnut. As soon as the faucet is firmly in place, the supply pipelines can be connected to the tails of the taps. The faucets can either be linked by utilizing corrugated copper piping or with typical tap adapters. The previous type should be connected to the tap finishes initially, tightening up just by hand. The supply pipelines can later on be linked to the other end. Tighten both ends with a spanner after both ends have actually been attached.

    Installing the Bath tub


    Making use of both wooden boards under its feet, position the bath tub in the required placement. The wooden boards are practical in evenly spreading the weight of the bathtub over the location of the boards as opposed to concentrating all the weight onto 4 little points.
    The next goal is to ensure that the tub is leveled all round. This can be achieved by examining the spirit level and also readjusting the feet on the bathtub till the spirit level reads degree.
    To mount faucets, fit the bottom of the furthest flexible tap port to the appropriate supply pipe by making a compression sign up with; after that do the same for the other faucet.
    Switch on the water system as well as inspect all joints as well as brand-new pipework for leakages and also tighten them if needed. Fill the bath tub and additionally inspect the overflow electrical outlet as well as the normal electrical outlet for leakages.
    Lastly, take care of the bath paneling as described in the producer's instruction manual. Tiling and sealing around the bathtub ought to wait up until the bath tub has been used at least when as this will settle it into its final placement.

    Getting ready for the Setup


    To start with, the supporting structure supplied with the bathroom should be fitted (if required) according to the producer's instructions. Next, fit the taps or mixer to the tub. When fitting the tap block, it is necessary to make sure that if the tap features a plastic washer, it is fitted between the bath and also the faucets. On a plastic bath, it is additionally sensible to fit a supporting plate under the faucets system to prevent pressure on the tub.
    Fit the flexible tap adapters to the bottom of both faucets utilizing 2 nuts and olives (in some cases supplied with the tub). Fit the plug-hole outlet by smearing mastic filler round the sink outlet hole, and after that pass the outlet via the hole in the bathroom. Use the nut provided by the producer to fit the plug-hole. Check out the plug-hole electrical outlet for an inlet on the side for the overflow pipe.
    Next, fit the end of the versatile overflow pipe to the overflow electrical outlet. After that, screw the pipeline to the overflow face which must be fitted inside the bath. Ensure you utilize every one of the provided washers.
    Link the trap to the bottom of the waste outlet on the bathtub by winding the thread of the waste electrical outlet with silicone mastic or PTFE tape, and also screw on the catch to the electrical outlet. Connect all-time low of the overflow tube in a similar manner.The bathroom need to now prepare to be suited its final position.

    Tiling Around the Bathtub


    In the location where the bath fulfills the ceramic tile, it is essential to seal the accompanies a silicone rubber caulking. This is very important as the fitting can move enough to split a rigid seal, causing the water to penetrate the wall between the bath and also the tiling, bring about issues with dampness and also feasible leakages to the ceiling below.
    You can pick from a range of coloured sealers to assimilate your fixtures and fittings. They are marketed in tubes and cartridges, as well as are capable of sealing voids as much as a width of 3mm (1/8 inch). If you have a larger space to load, you can fill it with twists of drenched paper or soft rope. Remember to constantly fill the tub with water prior to sealing, to allow for the motion experienced when the tub is in usage. The sealant can split relatively early if you do not think about this movement prior to securing.
    Conversely, ceramic coving or quadrant ceramic tiles can be utilized to edge the bathroom or shower tray. Plastic strips of coving, which are easy to use and also cut to size, are likewise easily available on the market. It is a good idea to fit the ceramic tiles making use of water-resistant or water-proof glue as well as grout.

    Bathtub Installation


    How Important Is A Bathtub To Your Home?


    High-quality baths, showers, and other bathroom updates are necessary when considering a smart investment in your home. It’s a room that you go to every day and one that is constantly being used by guests.The bathroom is one of the top trafficked rooms in a home and also one of the most valuable in terms of home resale.


    Install Piping Before Tub


    You will be using your existing drain and waste vent system, but pipes required include the hot and cold water supply lines and a pipe leading to a shower head. A mixing valve and shower head are also needed. Air chambers may be required.


    Position the Tub


    Lower the tub into place so that the continuous flange fits against the wall studs and rests on 1’x4' or 2’x4' supports. Anchor the tub to the enclosure with nails or screws inserted through the flanges into the studs.



    NOTE: Remember, bathtubs and shower stalls may require support framing. A bathtub filled with water is extremely heavy, so check building codes and framing support before installing the tub.


    Assemble Drain Connections


    Assemble the bathtub drain connections by connecting the tub overflow with the tub drain above the trap, not beyond it. The trap will have a compression fitting that screws over the arm of the overflow assembly.


    Place a Pipe For the Shower Head


    First, locate a brass female threaded winged fitting and attach it to a framing support via a screw or a nail. Then run a pipe up the wall for the shower head. Sweat or solder the other side of the brass fitting to the top of the pipe.


    Attaching Hot and Cold Water Lines


    Attach your water lines for both hot and cold by sweating these directly into the hot and cold ports of the mixing valve. The mixing valve will be how water enters the tub’s system, not by the pipes themselves.


    Install the Spout


    Extend a piece of 1/2 inch pipe, or whichever length is specified in the manufacturer’s instructions, for the tub spout. Sweat on a male threaded fitting at the end of the pipe or use a brass nipple of the proper length and a 1/2 inch cap.



    NOTE: At this point you should have your rough-in plumbing work inspected before proceeding further.


    Check For Leaks


    Restore the water pressure and check the drain connection and the supply pipes for any sign of leaking.


    estore the Bathroom Wall


    Replace the wall with moisture-resistant drywall as a base for your wall covering. Seal the joints between the wall and your new tub with silicone caulk as protection against water seepage.
